Support on/off-grid AC coupling function
Support intelligent load management (customized)
Support BMS remote upgrade function (customize）
|
Model
|
R5KLNA
|
R6KLNA
|
R7K6LNA
|
R8KLNA
|
R10KLNA
|
|
PV input data
|
|||||
|
Max. PV input power (kW)
|
7.5
|
9
|
12
|
12
|
15
|
|
Max. PV input voltage (V)
|
500
|
||||
|
Min. PV input voltage (V)
|
120
|
||||
|
Start-up voltage (V)
|
120
|
||||
|
MPPT voltage range@full-load (V）
|
150-430
|
||||
|
Rated PV input voltage (V)
|
310
|
||||
|
No. of MPPT trackers
|
4
|
||||
|
No. of strings per MPPT tracker
|
1/1/1/1
|
||||
|
Max. input current per MPPT (A)
|
14/14/14/14
|
||||
|
Max. short-circuit current per MPPT (A)
|
22/22/22/22
|
||||
|
Battery input date
|
|||||
|
Battery type
|
Lithium-ion / Lead-acid
|
||||
|
Max. charge / discharge power (kW)
|
5
|
6
|
7.6
|
8
|
10
|
|
Battery voltage range (V)
|
40~60
|
||||
|
Battery voltage range@full-oad (V)
|
48~58
|
||||
|
Rated battery voltage
(V)
|
48
|
||||
|
Max. charging / discharging current (A)
|
120/120
|
135/135
|
190/190
|
190/190
|
190/210
|
|
Rated charge / discharge current (A)
|
120/120
|
135/135
|
190/190
|
190/190
|
190/210
|
|
Charging strategy for Li-lon battery
|
Self-adaption to BMS
|
||||
|
BMS
cdmmunication
|
CAN
|
||||
|
Protection
|
|||||
|
Supported protection
|
Arc fault protection, PV reverse polarity protection, Anti-islanding protection, Ground fault protection
Leakage current protection, Insulation resistance detection, Backup output short circuit protection,
AC under-voltage protection, AC output over-current protection, AC over-voltage protection, |
||||
|
Ingress protection
|
IP65 / NEMA 3R
|
||||
|
Communication
|
RS485, 4G (optional), Wi-Fi
|
||||
