Product Name
|
BA100040SW-SiC(EU)
|
|
Constant power range
|
40kW(300VDC ~ 1000VDC)
|
|
Output voltage
|
150VDC ~ 1000VDC
|
|
Output current
|
Efficiency
|
|
Efficiency
|
Peak efficiency>97%, rated efficiency>96% Peak efficiency>97.5%, rated efficiency>97%
|
|
Input Parameters
|
|
|
Input voltage
|
260VAC~530VAC
|
|
Input frequency
|
55±10Hz, rated input frequency 50/60Hz
|
|
THDi
|
≤ 5%
|
|
Power factor
|
Rated output load PF ≥ 0.99
|
|
Standby power
|
10W
|
|
Communication
|
|
|
Communication
|
CAN
|
|
Number of working modules
|
Max. 60
|
|
HMI
|
LED operating display
|
|
Physical Characteristics
|
|
|
Noise
|
<65dB
|
|
Cooling
|
Air
|
|
Dimension
|
300*84*437.5 (W*H*D/mm)
|
|
Weight
|
16kg
|
Product Features
